The Mysterious Case of Dr. Brauer's
SINGLE-RED SEA-DWELLER
Discovering The Very First
Gas Escape Valve Rolex
Introduction by Jake
I just completed my twelfth straight year of publishing Jake's Rolex World, so as I enter my thirteenth year I am excited to publish this amazing story from Jose who is our Horological Forensics Investigator. In a nutshell, in this article, Jose believes he has discovered the very first Rolex SINGLE-RED SEA-DWELLER that featured a gas escape valve. Jose's research findings are completely counterintuitive and radically contradict the previously assumed scholarship narrative on the subject.
When I began Jake's Rolex World in 2008 the world believed COMEX had developed the Rolex SEA-DWELLER with Rolex. This was far from the truth.
Founder Of COMEX, Henri Germain Delauze [1970]
In 2008 I became friends with and interviewed legendary NASA Astronaut, Scott Carpenter who told me of his adventures with the U.S. Navy SEALAB program as an Aquanaut, which served to bring forth the real and true history of the development of the Rolex SEA-DWELLER.
U.S. NASA Astronaut & SEALAB Aquanaut, Scott Carpenter (right) with Jacques-Yves Cousteau
Since 2008 I have published and put together my 20 Part Series titled, "The Complete History of the Rolex Submariner & SEA-DWELLER: Rolex's Conquest of the Ocean." Scott Carpenter introduced me to diving legend and former Rolex U.S.A. Executive, T. Walker Lloyd as well as legendary U.S. Navy SEALAB Aquanaut, Bob Barth.
U.S. NAVY SEALAB founders Dr. George Bond (top) and Walt Mazzone.
Over the past dozen years I have interviewed many, many other people related to this history, including SEALAB director, Walt Mazzone (pictured above), as well as Comex founder, Henri-Germain Delauze—all of which have contributed significantly to assisting Jose and myself in completing this most amazing Rolex history puzzle.
As Jose and I have worked together to discover more missing pieces of this amazing history, we stumbled into many other pieces we never imagined could have existed, and each of these new puzzle pieces have significantly changed and enhanced our scholarship on this subject. Jose's story below my synopsis makes a significant contribution to furthering our understanding of so many aspects of this amazing previously undiscovered and undocumented meaningful Rolex history.
Synopsis
The mysterious Single Red SEA-DWELLER, hereinafter referred to by its acronym of SRSD models are super cool and until today have confused collectors to no end—that is, until Jose put together all the hyper complex pieces of the early SRSD puzzle in his brilliant story.
This story is very sophisticated and complicated. I would argue it's PhD level on the early history of the Rolex SEA-DWELLER, and even though I was very familiar with many of the facts, initially it was not easy for me wrap my head around all the details in this story. So I decided to share a brief synopsis with you to make it easier for you to comprehend and understand:
Rolex developed the Submariner diving watch in 1953 (as seen below in prototype form on Jacques-Yves Cousteau's wrist) and brought it to market in 1954 as the ultimate diving watch which was so versatile it could also be worn with a wetsuit, jeans, a suit or even with a black tie.
This first model could only dive down to 100 Meters which was more than enough for most divers a the time. Jacques-Yves Cousteau's diving team tested the prototype Submariner models for Rolex in Cannes, France in 1953 as we see from the document below from the Institute of SubmarinerResearch.
In the early 1950s mankind had just began untethered SCUBA diving and exploring the ocean. A decade after the Rolex Submariner came out, divers kept exploring deeper and deeper into the seas, so in 1967 Rolex decided to make a DEEP-SEA Submariner, which they dubbed SEA-DWELLER as we see pictured below.
The SEA-DWELLER model added a date window aperture complication and notice on the dial pictured above there is a single red line of text that says in red: "SEA-DWELLER", but notice on the second line in white text it reads "SUBMARINER 500M-1650FT. The standard Submariner at the time could only dive to 200 Meters which was 657 feet, but Rolex rounded up to 670 feet. Essentially the first SEA-DWELLER was a much deeper Submariner variant which it remains to this day.
Rolex completed its first batch of 40 or so prototype Single Red SEA-DWELLER models in between April & June of 1967 (II.67). At the time the SRSD prototypes were originally manufactured none of them had gas release valves or 'Patent Pending' engravings on their case-backs.
Rolex made the first SEA-DWELLER models as Jose calls them as a "Uber Submariner", meaning a Submariner that could be worn in the Deep Sea. Rolex planned to test these first prototypes with the U.S. Navy SEALAB program which was originally scheduled to take place in late 1967, but was postponed until early 1969. So basically, Rolex had the Single Red SEA-DWELLER models in the United States ready to test in mid 1967.
Then Rolex discovered through T. Walker Lloyd and U.S. Navy SEALAB Aquanaut, Bob Barth that there was a potential issue with the crystals popping off the watches when the diver would come up during decompression where helium would build up in the case and cause the crystal to explode off the watch. Bob Barth came up with the idea of putting a helium release valve on the watches and T. Walker Lloyd sent the idea to Rolex in Geneva.
In early/mid 1968 Rolex made the first Single Red SEA-DWELLER with a gas release valve, and it featured a 'Patent Pending' case-back engraving. Rolex gave this watch to Dr. Ralph Brauer to test in the Hydra project in Europe and once it worked as expected, in late 1968 Rolex retrofitted the fist batch of 1967 prototypes by replacing their plain case-backs with 'Patent Pending' case-backs, and modified the models that were destined for the SEALAB 3 Habitat mission with gas release valves, while leaving the ones for the DEEPSTAR 4000 mission and Tektite missions without gas escape valves as they were not necessary for their respective missions.
In effect this gave Rolex time to retrofit the first batch of Single Red SEA-DWELLER models to match Dr. Brauer's later 1968 SRSD prototype with the valve and etched case-back which explains why a SRSD made in 1968 had a gas release valve before the 1967 SRSD prototypes did!
In the photo below, taken in December of 1968 we see the DEEPSTAR 4000 Submersible as it prepares to inspect the SEALAB 3 Habitat off the California coast in the waters off San Clemente Island.
In the photo below we see DEEPSTAR 4000 pilot, Bob Bradley wearing his Single Red SEA-DWELLER. The SRSD models given by Rolex to the DEEPSTAR 4000 project did not require gas release valves as the submersible used normal air inside.
The Rolex magazine Submariner advertisement below from 1968 features the DEEPSTAR 4000 Submersible two man support crew.
Operation Tektite
As the U.S. Navy begun winding down Operation SEALAB, Rolex continued to test SEA-DWELLER Prototypes with The U.S. Navy Office of Naval Research Operation Tektite, which had an underwater habitat in Great Lameshur Bay, in The Saint John, U.S. Virgin Islands which you can see in the background below as the team of Tektite Aquanauts swim away from her.
The Tektite habitat was built by the Space Division at General Electric at the Valley Forge Space Technology Center located in King Of Prussia, in Pennsylvania as we see pictured below. Tektite I was a mission with four aquanauts, and it began on February 15, 1969 and ran until April 15, 1969.
The two photos below show Tektite I Aquanaut, Ian Koblick wearing his Single Red SEA-DWELLER which lacks a gas escape valve.
The Tektite Aquanauts didn't require gas escape valves on their Single Red Rolex SEA-DWELLER models. This was due to the fact the Tektite Habitat was saturated with Nitrox, which was a combination of Nitrogen & Oxygen not to mention the Tektite Habitat was in relatively shallow water at less than 50 feet.
"This is your last chance. After this, there is no turning back. You take the blue pill—the story ends, you wake up in your bed and believe whatever you want to believe. You take the red pill—you stay in Wonderland, and I show you how deep the rabbit hole goes. Remember: all I'm offering is the truth. Nothing more."
I understand how this early SRSD history may seen highly esoteric, arcane and watch-geeky, and it is, but at the same time it is utterly fascinating as it shows Rolex's hardcore R&D prowess and aim toward constant improvement. With this overview knowledge and understanding, I think you will better enjoy and understand this story, so if you dare, take the Red pill and jump into the Rolex time machine with Jose to explore the deep sea underwater world or the SRSD!
Jake :-)
THE
SEA-DWELLER
CHRONICLES
GENESIS OF THE DECOMPRESSION WATCH
The Rolex Sea-Dweller is without a doubt one of the most fascinating Rolex models ever created. Collectors love the SEA-DWELLER, but what is the Genesis of this beloved Rolex model, and how, when and why did it get its trademark feature of a helium release valve? The truth is the SEA-DWELLER was shaped by historical events and awesome human ingenuity and it was developed as a toolwatch for a new generation of deep divers that emerged from experimental saturation dives in the mid 1960s. With saturation diving, the manufacturers of diving watches were faced with a new set of challenges.
Years of meticulous research made it possible to identify what I believe to be the very first Rolex Sea-Dweller valve prototype. The story of this watch is nothing short of amazing as it appears to have been specifically made to be tested during one of the most daring missions in the history of diving. Ironically, when I recorded this first SEA-DWELLER with a prototype gas escape valve in my database back in 2016, its case number gave me headaches and confused me terribly. Sometimes it’s the strange things that hold the best secrets.
The Sea-Dweller Chronicles: Genesis of the Decompressing Watch is the first of two articles on the earliest Rolex Sea-Dwellers made between 1967 and 1971. The report you are about to read is one of those fascinating stories that was almost lost to antiquity for the simple reason the initial owner of the watch was basically a ghost and any information about him was nearly impossible to find.
Rolex SEA-DWELLER made between 1967 and 1971/72 are a bit of a mystery as there seems to be no clear chronology. There are earlier case numbers with later dials and later watches that feature Patent Pending case-backs, whereas the earlier ones do not. Then there is the signature feature that defines the Sea-Dweller—the Gas Escape Valve—which is strangely non-existent in some of the watches? What appears like complete chaos falls into perfect order once you discover the highly counter-intuitive key that unlocks all the secrets of these watches.
Let's start with the patent for the Gas Escape Valve as it is the most important milestone in the development of the Sea-Dweller. Rolex filed the patent application on November 6, 1967.
Interestingly, the very first Sea-Dweller models, the so-called 'Single Red' which featured a depth rating of 1650 ft/500 m, are marked II.67 on the inside of their case-backs—suggesting they were produced in the second quarter of 1967. That would be between April and June 1967, at least four months before the patent application was filed.
Caseback of case number 1602913 originally owned by Deepstar 4000 pilot Bob Bradly
This fact leads me to believe the initial SEA-DWELLER was conceived as some sort of Uber Submariner with a considerably increased water resistance of 1650 ft/500 m as opposed to 660 ft/200 m of the normal Submariner (Ref. 5512/5513). In other words, when I say the first batch of Single Red SEA-DWELLER models were an 'Uber Submariner', I mean they were like a Submariner on steroids that could dive even deeper.
When these watches were made, Rolex was most certainly not yet aware of the issues posed by helium entering the watches and accordingly the majority of these watches do not have a valve. More on this later.
The name SEA-DWELLER was a direct reference to the world famous U.S. Navy SEALAB divers known as Aquanauts, as well as a nod to Jacques-Yves Cousteau's Conshelf Aquanauts who were the very first men to 'dwell' in the SEA. While Astronauts were responsible for exploring outer space, Aquanauts submerged themselves into the so-called 'Inner Space'.
Single Red Sea-Dweller dial
A new method known as saturation diving developed by U.S. Navy physician George F. Bond (A.K.A. Papa Topside) in the late 1950s enabled Aquanuats to spend days or even weeks in a row living in underwater habitats at the bottom of the ocean.
U.S. Navy Doctor, Captain George F. Bond founded SEALAB
The Aquanuats became free agents of the sea, literally 'dwelling' in and around their underwater habit environments.
“…to go further, men have begun to go down to the sea, not to frolick, not to play within it but to DWELL, to live for a while…”
—SEALAB 2 Documentary from 1966.
To make a prolonged stay in a deep sea habitat, the Aquanauts were required to breath a special breathing gas composed of 95% helium (He) and 5% oxygen (O2) until their body tissues became completely saturated with the gas. Saturated divers could stay at depth indefinitely and decompression was only required at the end of the dive.
Prior to Dr. Bond’s saturation theory, depth and duration of deep dives was extremely limited by the anesthetizing and intoxicating effects of regular air in pressurized environments (e.g. nitrogen narcosis and oxygen toxicity). A dive to 195 ft/60 m of depth was only possible for around 15 minutes and required lenghty decompression after each dive which made working at depth almost impossible.
With saturation diving, going underwater was no longer just a matter of minutes, it could last for days or even weeks provided the divers had a dry underwater habitat. With this in mind, Rolex equipped the SEA-DWELLER model with a date complication to help Aquanauts keep track of life on the surface. To emphasize the new date function, the Single Red Sea-Dweller dial had the word Date printed in larger letters (as seen below) than OYSTER PERPETUAL, and it maintained the 'SUBMARINER' dial designation which means it was a Submariner variant, which it remains to this day.
Ian Koblick’s SRSD (Photo: Silas Leung aka @silas815)
With every new saturation diving experiment—whether in a hyperbaric chamber or in the open sea— the Aquanauts went deeper and deeper.
In mid 1966, following the success of SEALAB 2, the U.S. Navy greenlighted SEALAB 3. The plan was to lower an updated version of the SEALAB 2 habitat to a depth of 450 ft/137 m. The Aquanauts living in the habitat would attempt to go down to 600 ft/183 m.
At 600 ft/183 m, a then contemporary standard Rolex Submariner 5512/5513 with a depth rating of 660 ft/200 m as used by the majority of Aquanauts during SEALAB 2 (205 ft/62 m) was already near its limits.
NASA Astronaut & SEALAB Aquanaut Scott Carpenter wearing his Rolex Submariner during the presentation of the new SEALAB 2 habitat in 1965
The picture below shows one of around 25 examples of the Rolex Submariner Ref. 5512 delivered to the U.S. Navy for SEALAB 2.
Excited about the immense possibilities of saturation diving, Rolex developed Reference 1665, an 'Uber Submariner' with a significantly increased depth rating of 1650 ft/500 m.
Between April and June 1967, Rolex produced the very first batch of around 40 Single Red Sea-Dweller prototypes specifically made for the upcoming U.S. Navy SEALAB 3 mission scheduled for October 1967.
The U.S. Navy SEALAB scheduled, five, eight-man teams to live in the habitat for a total of 60 days. All these watches are hand etched with the American Rolex import code 'ROW' as seen on the balance bridge in the circled in the picture below since they were imported to the U.S.
Movement of Ian Koblick’s SRSD (Photo: Philipp Stahl aka @rolexpassionreport)
Aware of the marketing potential equipping the SEALAB Aquanauts with the new 'Uber Submariner' would have, Rolex launched the serial production (1.7 million) of this model. Thousands of cases were produced including case-backs stamped IV.67 (fourth quarter 1967). This move turned out to be premature.
EXPLODING WATCHES
Around the same time, U.S. Navy Aquanaut and pioneer in saturation diving, Bob Barth (pictured below) met a deep sea diver named T. Walker Lloyd at a diving trade show in New York. T. Walker Lloyd was an archeological diver mostly diving on compressed air. He was preparing for an archaeological excavation off the coast of Bodrum in Turkey led by underwater archeologist Dr. George Bass.
During their conversation about saturation diving, Bob mentioned a fascinating phenomenon T. Walker Lloyd had never heard of. When saturation divers went through decompression after weeks at depth, their watches literally exploded! In other words, the crystals would shoot off the watches, which was really dangerous when a diver is in a diving bell. The reason being helium molecules were so tiny, they were able to penetrate the watch cases during prolonged dives but could not escape at the same rate as the diver decompressed.
Bob Barth during an experiment in which he was required to breath a special gas mixture after decompression
Once saturation divers started the process of decompression, the helium inside the watches could not escape fast enough and became trapped. The internal pressure—now much higher than the steadily decreasing pressure in the decompression chamber— caused the weakest part of the watches, the crystals, to pop/shoot off.
The divers learned quickly how to deal with this issue. Before decompression, they simply unscrewed their crowns. If they forgot, however, their watches could be damaged. An automatic 'set it and forget it' solution was needed and Bob Barth had already figured out what to do. His idea was simple yet brilliant: To install a tiny one-way valve to allow accumulated helium gas to exit the watch in a controlled fashion.
After this encounter, T. Walker Lloyd seized the moment and shared the acquired knowledge with Rolex in Geneva. This is when Rolex became aware their latest SEA-DWELLER model was lacking and potentially not up-to-the-task. Serial production of the watch had already begun (1.7 million) and this new information forced Rolex back to the drawing board. André Heiniger, the director of Rolex at the time was a diver himself, and was fascinated by Lloyd’s knowledge of saturation diving, so much so, he offered him a job as Oceanographic Consultant for Rolex in order to keep in touch with the latest developments.
T. Walker Lloyd’s role in the development of the valve was mentioned in one of Rolex’s oldest Sea-Dweller advertisements which featured a Double Red SEA-DWELLER (pictured below).
Rolex Sea-Dweller 1665 ad from 1974 (Photo: Nick @adpatina)
“The Rolex Sea Dweller, however, is fitted with a patented gas escape valve. As the Oceanographic Consultant for Rolex, T. Walker Lloyd has kept in touch with the development of this unique feature since its conception.”
Around the same time, the Swiss watch company Omega started working with the emerging French diving company COMEX (Compagnie Martime d’Expertise) to develop a new generation of professional diving watches for the specific purpose of saturation diving. Omega knew of the helium release issue and their approach was to create a watch so tight and solid helium could not enter the case.
Nobody was pushing the envelope like Comex. In 1965, they developed their first bell-chamber system named Idéfix with a diving bell locked onto a deck decompression chamber which divers transferred to when the bell was brought to the surface.
With a super innovative saturation diving system like this in place, Comex established a record-breaking dive to a depth of 525 ft/160 m in 1966 and became famous overnight. This accomplishment resulted in a lucrative contract for a pipeline repair job off the coast of Greece (345 ft/105 m), followed by jobs from major Oil companies which ultimately led to Comex’s meteoric rise to industrial success.
Comex advertisement from 1967 showing their bell-chamber system named Doris
Rolex had to move fast as they lost the prestigious race to Outer Space against Omega’s formidable Speedmaster Professional and were under massive pressure to win this new race to conquer the so-called Inner Space.
André Zibach, a former Patek Philippe watchmaker working for Rolex since the mid 1960s, designed the actual Gas Escape Valve. The goal was clearly to create a simple and elegant solution that could also be easily retrofitted to already produced watch batches. The corresponding patent was quickly filed on November 6, 1967.
The valve idea saved Rolex from having to invest in developing a completely new watch for saturation diving. The Oyster case remained untouched in its concept. As mentioned earlier, Omega’s approach was to prevent helium from entering the watch in the first place.
The funtional principle of the helium release valve is quite simple. Since it is a one-way valve, no water can enter the case. External pressure pushes the valve stem against the rubber gasket creating an impenetrable seal. Accumulated helium on the inside of the case can escape in a controlled method as soon as a certain inside pressure is reached. In saturation diving this process occurs always in dry decompression chambers.
The valve worked well in theory but how would it perform under real life conditions in a helium atmosphere? Rolex had no infrastructure to test the device and SEALAB 3 was postponed to late 1968 as it had no top priority in the Navy due to the Vietnam War and other defense requirements.
COMEX PHYSALIE
On March 5, 1968, Comex surprised the world with a spectacular record dive named Project Physalie in which Comex founder Henri Germain Delauze and American physiologist and leading hyperbaric researcher Prof. Dr. Ralph Werner Brauer descended to the equivalent of 1100 ft/335 m in a pressure chamber at the Comex Hyperbaric Center in Marseille, France.
With the news of the record dive, Comex and Dr. Brauer announced an even more radical and daring experiment in the open sea with the awe-inspiring name Hydra 1, the first human trial to involve highly explosive hydrogen gas.
The primary goal of Physalie 1 was to trigger a condition known as helium tremors which was first discovered in 1965 by Dr. Peter B. Bennett during rapid compression experiments for deep submarine escape methods conducted by the Royal Navy. Researchers assumed man had reached a physiological barrier that would make it impossible to dive deeper than 1000 ft/300 m.
In 1966, Dr. Brauer started working on solving this problem. He figured thanks to its unique characteristics, hydrogen could replace helium at pressures beyong the helium barrier. A series of animal tests proved the feasibility of his theories.
To be able to experience and accurately describe the helium tremors himself, Dr. Brauer volunteered to climb into the hyperbaric chamber and be his own guinea pig. Asked what his motivations were, Brauer replied:
“As an investigator I can see more by climbing into a given situation than someone who has not worried about why these things work. My ears are tuned more keenly to little changes and I can interpret the fact that my little finger tingles where a much more experienced diver would long ago have learned that one ignores things like that. I don’t. I listen to that little finger because this may mean I have an interesting change in blood circulation that I can use. Or I can interpret other effects of nitrogen narcosis or inert narcosis. Not only do we get absolute data, but by going to get it we see things we haven’t seen before and that allows us to make sense of the situation.”
As hoped, Brauer experienced the tremors during Physalie 1, but they were accompanied by a number of other symptoms like somnolence and decreased mental performance. After a few minutes at depth, the descent was reversed and after days of decompression, he and Henri Delauze returned safely to normal surface pressure. Thanks to the gathered data, it became apparent the problems were not caused by helium but rather by the extreme pressure. Dr. Brauer was first scientist to describe the disorder in its entirety and coined the phrase High Pressure Nervous Syndrome.
The picture below shows Henri Delauze and Dr. Ralph W. Brauer (right) during the experiment inside the hyperbaric chamber. The bandages on Brauer’s head and leg were needed to secure a number of implanted electrodes that measured his brain activity, etc., during the experiment.
COMEX founder Henri Delauze and Dr. Ralph W. Brauer (right)
during the experiment inside the hyperbaric chamber
As mentioned earlier, Comex was cooperating with Omega at the time and as a matter of fact, the above picture shows Brauer wearing a massive Omega Seamaster 300 prototype.
Dr. Brauer passed away unexpectedly in fall 2000 and having no family, the University of North Carolina Wilmington where he was a long tenured professor inherited his entire estate. This consisted of thousands of papers, science books and a multi-faceted artifact collection contaning numerous fascinating items.
Among these items was a super rare Rolex Single Red Sea-Dweller with Gas Escape Valve made in early/mid 1968 which is pictured below.
Dr. Brauer’s unique Single Red Sea-Dweller (Photo: John Goldberger, @goldberger)
According to Brauer’s assistant, the Single Red Sea-Dweller was found hidden under Brauer’s mattress, together with cash and a handgun. Incredible as this may sound, Dr. Brauer was a real life Indiana Jones with ties to the secret services and a true explorer always hunting for the ultimate adventure.
DR. RALPH WERNER BRAUER
In his public life, Dr. Brauer was a professor of physiology at Duke University and director of the Wrightsville Marine Biomedical Laboratory of the University of North Carolina Wilmington.
The picture below taken during the workshop Techniques for diving deeper than 1,500 feet of the Undersea & Hyperbaric Medical Society (UHMS) in 1980 shows Dr. Ralph Brauer (front, 3rd from right) among other famous hyperbaric researchers like Peter B. Bennett (front, 5th from left) and Medical Director of Comex Dr. Xavier Fructus (behind Brauer).
Workshop “Techniques for diving deeper than 1,500 feet”, March 1980
Dr. Ralph W. Brauer had an amazing resume. Born in Berlin in 1921, he and his widowed father Dr. Frederick Brauer fled Nazi Germany in 1937. When war broke out in Europe, Ralph’s father obtained a presidential exemption from classification as enemy alien. In 1943, both became American citizens. At age 21, Ralph Brauer earned his doctorate in biochemistry. He was the youngest recipient of a Ph.D. from the University of Rochester.
After years of teaching at Harvard Medical School, Brauer started working for the U.S. government as Head of the Pharmacological Branch of the U.S. Naval Radiological Defense Laboratory in San Francisco, the U.S. military’s largest facility for applied nuclear research.
As a member of the Atomic Energy Commission, Brauer embarked in 1964 on a expedition to the high Andes of southern Peru to study cosmic radiation effects on indigenous people genetically related to the Inkas.
Brauer spoke six languages, plus some Peruvian Indian dialects. He was in frequent contact with SEALAB and Jacques Cousteau’s team, especially their medical director Dr. Xavier Fructus. According to a 1971 newspaper report, Brauer was the only American ever invited to participate in the Soviet Union’s deep-sea projects.
Brauer was travelling all the time. It was a running joke at the university how each time Brauer travelled, some mayhem or disaster would occur at his destination. For example, during a 1972 research expedition to Lake Managua in Nicaragua, Brauer and two of his students went missing after a devastating earthquake killed more than 5,000 people and left 90% of Managua destroyed.
One of Brauer’s assistants implied the doctor had ties to the CIA. As a founding member of the Undersea & Hyperbaric Medical Society (UHMS) established in April 1967, Dr. Brauer was involved in top-secret projects for the US Government to conquer the so-called Inner Space ahead of the Soviets. Information on Dr. Brauer is almost impossible to find today. He was very low-profile, probably for good reasons.
In 1978, Dr. Brauer and three of his colleagues were allowed to travel to the USSR—in the midst of the cold war—to do research on Lake Baikal, the world’s deepest and most ancient lake in southern Siberia. During this endeavor, Brauer was allowed to use explosives and even radioactive materials for his research. According to one of his assistants, Brauer was asked by the U.S. Government to try and extract valuable information from the Soviet officials looking after them. All this while, Brauer was secretly taking pictures with a micro camera.
After this short glimpse at the man behind the watch, it is time to take a closer look at his Rolex watch.
ROLEX SINGLE RED SEA-DWELLER
Serial 1820177
With 1820177, Brauer’s watch has an absolutely unique case number which was just confirmed by Rolex Geneva as pertaining to a 1665 manufactured in 1968. The case number suggests a production date in early/mid 1968 and appears to be more or less random. The caseback is stamped IV.67.
Apart from Brauer’s watch, there are no other known Sea-Dwellers in the 1.8 million range. But the uniqueness of this watch does not end here.
To properly assess Brauer’s watch it is essential to understand the production timeline. As mentioned earlier, the chronology between 1967 and 1971 is not very clear. A good way to shed light on this is to take the movement serial numbers into consideration. Movement numbers have always been an important part of my database. As with all archives—the more data available—the clearer the picture.
Rolex collectors have been indoctrinated into thinking movements are of no, or, little importance but the fact is the numbers are crucial to determine whether a watch is completely original or not. Since everything was done in batches, every case batch was married with a corresponding movement batch. The term 'Matching Numbers' used in vintage car collecting to establish whether a chassis and engine were born together, can also be applied to vintage Rolex watches.
The earliest Single Red Sea-Dwellers from the 1.6 million range made between April and June 1967 (II.67) have movement serial numbers ranging between D60,000 and D75,000. These watches were imported to the United States of America as indicated by the U.S. import code 'ROW' etched on the balance bridges of their movements as seen below.
Caliber 1570 (1575) was an adjusted movement and therefore subject to a special import tax. Movements that were marked unadjusted were tax-free. The U.S. introduced these codes around 1934 to protect the American watch industry.
Sea-Dwellers with 1.7 million case numbers have movement serial numbers that average between D800,000 and D850,000. See the massive leap from 1.6 million to 1.7 million? There are, of course, exceptions to this rule. Most of them are later calibers made after Rolex reached 999,999 and started from zero again. Apart from movement serial numbers, there are other details that help determine when calibers were made.
An interessting observation is that none of the known 1.7 million Sea-Dwellers have movements with ROW import codes. The U.S. discontinued these codes in 1969, so logically, if the 1.7 million Sea-Dwellers were assembled in 1967 as often claimed, the watches imported to the US should bear a ROW import code.
In my opinion, the movement numbers of 1.7 million Sea-Dwellers are a clear indication that these watches were assembled in 1971, probably in the same breath as 2.6 million Sea-Dwellers that feature similar numbers. This assessment is further supported by the fact that most 1.7 million Sea-Dwellers feature Double Red Mk 2 dials.
2.1 million Patent Pending Sea-Dwellers made in 1969 have movement numbers ranging from D350,000 to D400,000.
2.2 million Patent Pending Sea-Dwellers have movement serial numbers around D550,000.
Both these batches have lower movement numbers than the 1.7 million Sea-Dwellers.
Below is a list of average movement numbers found on Sea-Dwellers made between 1967 and 1971:
1.6 million: D60,000 – D75,000
1.7 million: D800,000 – D850,000
1.8 million: D69,043
2.1 million: D350,000 – D400,000
2.2 million: D540,000 – D550,000
2.6 million: D800,000 – D850,000
See the pattern? This is why I love data! The movement numbers bring the true production timeline to light. In view of this, a logical explanation as to why 1.7 million Sea-Dwellers were assembled at a later moment in time could be the cases were not made to feature a valve in the first place. 1.7 mil Sea-Dwellers were most certainly conceived as Uber Submariners in the same fashion as 1.6 mil Single Red Sea-Dwellers. In order to make them into real Sea-Dwellers, the valve had to be retrofitted, a task Rolex procrastinated on until 1971. This topic will be covered in more detail in the second part of the The Sea-Dweller Chronicles that will be published soon.
Brauer’s watch is a one-off in this whole picture. With serial number D69043, its 1575 caliber is well within the movement serial number range of 1.6 million SRSDs. Movement and dial were probably assembled during the 1.6 mil production and kept in stock as a reserve.
It is important to note in 1968 Rolex had not yet developed the so-called Double Red dials. These were introduced in 1969 with 2.1 and 2.2 mil Sea-Dwellers.
Brauer’s watch—unlike the earliest Single Red Sea Dweller models—does not bear the U.S. import code ROW which was mandatory for U.S. import until around 1969. This is a clear evidence that suggests the watch was delivered within Europe.
And this is where it gets really interesting. Here is what I believe occurred:
After news broke of the record-breaking Physalie dive and the upcoming Hydra 1 hydrogen-oxygen experiment in the open sea, Rolex realized they were betting on the wrong horse. Note the U.S. Navy (SEALAB) was pushing the envelope at the time but commercial companies like Comex that were not slowed down by the constant requirement of the U.S. Navy to justify every step to higher authority. The only problem with Comex was, they were already highly involved with Omega.
Pictures of Brauer published in news articles in March 1968 showed him wearing a Rolex dive watch. Brauer was a Rolex guy and—more importantly—he was not a Comex employee. His cooperation with Comex was based on a joint venture between Comex and the Wrightsville Marine Biomedical Laboratory.
Picture of Dr. Ralph W. Brauer from the article “Experiment Will Take Scientist On a Radical Diving Expedition” published in The News and Observer on March 24, 1968
Through their contacts in the U.S., Rolex managed to get in touch with Dr. Brauer. During their subsequent exchange, Rolex learned in detail about Brauer’s radical idea to overcome the High Pressure Nervous Syndrome (HPNS) by replacing helium with hydrogen. Hydrogen is not only highly explosive, its molecules are small enough to easily enter watch cases as well. Brauer expected to encounter further barriers along the way which would possibly require the use of more gases.
It became apparent the valve was not exclusive to helium but likely needed to release other gases as well. As a result, Rolex decided to give the pressure release device a more general name like Gas Escape Valve. The caseback of Brauer’s watch, as seen below, was the first Sea-Dweller to ever feature this designation. More on this later.
Gas Escape Valve Designation (Photo: John Goldberger, @goldberger)
The first Physalie dive was a preliminary test for a much more radical experiment: Hydra 1, the first human trial to go beyond 1000 ft/300 m in the open sea while breathing a hydrogen-oxygen cocktail named Hydrox. As the mastermind behind the idea, Dr. Brauer volunteered to do the risky dive himself.
The name Hydra was not only carefully chosen for its similar sound to hydrogen, but also in reference to the terrifying serpentine water monster from Greek mythology that could regrow two heads for every head chopped off. Hydra 1 was a dangerous undertaking involving a highly explosive gas and nobody knew exactly what was going to occur.
Initially scheduled for May 8, 1968, Hydra 1 was postponed to June 1968, and then again to mid September 1968 due to civil disorder in France. Student protests and general strikes involving millions of workers paralized the French economy for weeks. Clashes between demonstrators and the authorities left Paris and other major French cities resembling war zones. Fearing a revolution, the French President Charles De Gaulle fled to Germany.
The following excerpt is from an article printed in the Rocky Mount Telegrame on April 21, 1968:
Deep Dive Project May Pave Way For Deeper Penetration Of Ocean
The deep-dive project, now scheduled for sometime between June 7 – 15, will take place off the coast of Marseilles, France. It has been named Hydra, ‘partly because of the critical role hydrogen will play and partly because almost as many heads will be involved as owned by the mythological monster,’ Brauer says.
Hydra 1 will be a joint venture of the Wrightsville Laboratory and Compagnie Maritime d’Expertises (Comex), a French firm that is interested in the development of deep-sea divingcraft and other diving techniques. Comex is headed by the senior scientist of the French Bathscaph Program, Dr. Henri Delauze.
Also involved in the program will be the hyperbaric oxygenation group at Duke Medical Center. Duke’s new hyperbaric chamber, capable of simulating atmospheric conditions found 1,000 feet beneath the sea, is being used for preliminary tests leading up to the deep diver off the coast of France.
Two people will accompany Brauer on the actual ocean dive: Andre Veyrune, Comex engineer and diver; and either Dr. Xavier Fructus, chief of medical research for Comex, or Fructus’ son, Dr. Pierre Fructus.
The three men will be lowered in the diving bell to a depth of 600 feet. At that point, Brauer and Veyrune will emerge from the bell and sit for a time on an attached platform.
Brauer will be heavily instrumented. Electrodes will be implanted into his scalp to provide constant monitoring of his brain waves. Gas analyzing equipment will monitor all of his exhalations.
Here Brauer will make a drastic departure from normal deep-diving routines. Until they reach 600 feet, all three divers will be breathing the conventional deep-dive mixture of helium and oxygen. But recent developments indicate that helium may have its limitations.
So Brauer will switch to a mixture of hydrogen and oxygen and the bell will be lowered deeper into the sea. He will be watched carefully by his companions. The monitoring devices will be scanned by other colleagues on the surface ship of Hydra.
If all goes well, the depths to which man can penetrate the ocean may be extended.
To take full advantage of the delay, Dr. Brauer decided to stay in Marseille and conduct further experiments to study the High Pressure Nervous Syndrome more closely. During this time, Dr. Brauer met with Rolex representatives and was presented his Rolex Single Red Sea-Dweller prototype with unique case number 1820177.
On June 11, Brauer established yet another record when he and Comex diver Renè Veyrunes were pressurized to the equivalent of 1181 ft/360 m of depth in Physalie 2. Only two weeks later on June 27, the same two men aimed for mind-blowing 1312 ft/400 m in Physalie 3 but were forced to stop at 1190 ft/365 m of depth due to alarming symptoms of the High Pressure Nervous Syndrome.
I don't believe it's far-fetched to believe Dr. Brauer smuggled a stowaway into the hyperbaric chamber during these two dives, namely his Single Red Sea-Dweller with Gas Escape Valve! The supreme irony is—officially—it was Omega that established a world record during Physalie 3 but the Rolex was right there with its Swiss brethren Omega.
After the Physalie test dives, Brauer went back to his lab in North Carolina to conduct final tests on primates before the actual dive. Monkeys breathing hydrogen-oxygen were successfully pressurized to the equivalent of 2,100 ft/640 m of depth and brought back to surface pressure with no apparent ill effects. Everything was ready for Hydra 1.
Hydrogen gas is inexpensive compared to helium but much more difficult to handle. Remember the Hindenburg disaster from May 6, 1937? The Hindenburg was filled with hydrogen, a highly flammable, lighter-than-air gas that provided the airship’s lift.
For safety reasons, Hydra 1 took place outside the diving bell where the surrounding water could provide insulation against possible leakage. The experiment was again delayed and took finally place on October 28, 1968.
The picture below shows Dr. Ralph Brauer geared up and ready for the dive. Just hours before the descent, an ear problem denied Dr. Brauer the possibility to set another amazing deep dive record. He was replaced by Comex diver François Fallourd.
It is unknown which watch Brauer was wearing in this photo. For Hydra 1, Omega provided Comex with five special PloProf prototype watches. PloProf was short for Plongeur Professionnel = professional diver.
Omega PloProf Prototype (Photo: Monochrome)
Omega’s plan was to use Hydra 1 for a big press release to promote their diving watches fell flat as the goal to break the 1000 ft/300 m depth barrier in the open sea could not be accomplished. At a depth of 826 ft/252 m, Hydra 1 had to be aborted after the divers almost froze to death as a result of the chilling water temperature, as their heated diving suits did not perform as expected.
The Hydra experimental deep dive series led to two world records that still stand today. The offshore record was established during Hydra 8 in March 1988 when two Comex divers did actual work at a depth of 1752 ft/534 m as seen in the picture below.
The onshore record was achieved during Hydra 10 with a simulated hyperbaric dive to 2,300 ft/701 m established in 1992.
Théo Mavrostomos at a pressure equal to 2300 ft/701 m
Both world records were only possible thanks to Dr. Brauer’s scientific work. If Dr. George F. Bond was the father of saturation diving, Dr. Brauer was the guy who brought it to a whole new depth.
BRAUER’S SINGLE RED SEA-DWELLER
UNDER THE LOUPE
Brauer’s Rolex has several unique features which suggest it was the very first Sea-Dweller to feature a valve. First there is, of course, the unique case number 1820177. The question that arises is why did Rolex not simply send Brauer a 1.7 million Sea-Dweller? Why make a special watch? The only plausible answer is the 1.7 million Sea-Dwellers were initially not made to feature a valve. Instead of trying to retrofit the valve into an existing case, Rolex designed Brauer’s watch case from scatch with enought space to incorporate the valve perfectly.
There are at least three known 1.6 million Single Red Sea Dweller models that feature a Gas Escape Valve. The way the valve is installed compared to Brauer’s watch and the fact these watches were distributed among SEALAB 3 participants in October 1968—several months after Brauer got his—suggests the valves were retrofitted by the Rolex U.S.A. service center. 1.6 mil SRSDs without valve were given to Deepstar 4000 submersible pilots in November 1968 and to Tektite 1 Aquanauts in February 1969.
A closer look at the case shape of Brauer’s watch reveals significant differences compared to 1.6 million SRSDs and 1.7 million DRSDs respectively. This becomes particularly apparent in the profile view. To better accommodate the valve, the case of Brauer’s watch (bottom) is slightly thicker in the center, giving the lugs a more streamlined appearance.
Being a prototype in the truest sense of the word, Brauer’s Single Red SEA-DWELLER was made with special care. Unlike later serial production pieces, every detail on Brauer’s watch is super precise.
To fully grasp the importance of Brauer’s watch it is essential to dive deep into it and explore the way the valve was installed on the inside of the case. The first generation Gas Escape Valve of Ref. 1665 is quite rudimentary and consists of only three parts. The valve stem (1), a rubber gasket (2) and a flat spring made of spring steel (3).
Here is how the Gas Escape Valve works:
The valve stem (1) is kept in place by the flat spring (3). When a certain inside pressure is reached due to accumulation of helium, the trapped gas pushes the valve stem outwards against the resistance of the flat spring in order to escape in a controlled fashion. Water cannot enter the case as external pressure keeps the valve stem pushed against the rubber gasket, hence creating a impenetrable seal. In addition, decompression always takes place in dry hyperbaric chambers.
The next picture shows the perfectly fitted valve inside Brauer’s watch. Interestingly, not all valves in Ref. 1665 are fitted with the same accuracy.
Valve detail 1820177 (Photo: John Goldberger, @goldberger)
The following comparison shows Brauer’s prototype vs. one of the SRSDs from the 1.6 million batch that features a valve. Brauer’s watch has a precisely machined seat for the flat spring. On the 1.6 mil SRSD, the valve looks like an after thought. It was installed/retrofitted in a rather improvised fashion in a case that in my opinion was never meant to have a valve.
On the inside of the 1.6 mil SRSD there is notably less space than in Brauer’s watch and accordingly, the flat spring has a reduced width. This is absolutely consistent with the prior observation that Brauer’s watch case is slightly thicker in the center.
The valve stem itself (1) is notably different in shape. On Brauer’s watch, the stem looks like an precisely machined part. The same bit looks rather raw, primitive and imprecise on the 1.6 mil SRSD.
A comparison of Brauer’s watch with a later prototype from the 2.1 million batch shows the valve is fitted in almost identical fashion. The valve stem on the later watch has a bevel which gives it a more refined look. Interestingly, the valve stem found in the 1.6 mil Single Red Sea-Dweller shown above looks closer to this than to Brauer’s.
A closer look at the above comparison reveals also that the 2.1 mil case is slightly thicker compared to Brauer’s watch (see frame below). A profile comparison confirms this observation, in addition to show the obvious differences in shape. The lugs on Brauer’s watch appear more streamlined.
Another thing interesting to note is the difference between early Sea-Dweller bezels and those of later batches. The knurling at the edge is notably deeper in early bezels.
A comparison between Brauer’s watch and a Double Red Mk2 Sea-Dweller from one of the 1.7 mil batches shows how little space there is inside the latter. The width of valve spring is considerably smaller, almost identical to the retrofitted 1.6 mil valve.
The discrepancies between Brauer’s watch and the earliest 1.6 mil SRSDs with valve are in my opinion a clear indication that the valves on 1.6 mil SRSDs and 1.7 mil DRSDs were retrofitted. More on this in part two of The Sea-Dweller Chronicles.
Another interesting detail that supports my Rolex Service Center hypothosis is the way the Oyster Gas Escape Valve (Patent Pending) inscription was applied. This designation became necessary since the patent was still under review in 1968. At the time of the filing, the Swiss Patent Office was overwelmed with thousands of patent applications which ultimatelly led to enormous delays. A process that would normally take one year, required more than two and a half years.
The picture below compares Brauer’s watch (top) to the other two known examples from the 1.6 million range. The first thing to note is that on all three casebacks the typeface looks like handwriting. A closer look reveals the typeface on Brauer’s watch is slightly different than on the two other examples which appear to be almost identical.
The Patent Pending case-back designation offers a similar picture. In addition, the letter-spacing between VA of Valve and PA of Patent is inconsistent in the two other examples. Those letters are too close to each other. The insciption on Brauer’s watch appears to have been made by someone with a better sense for typography.
The letters on Brauer’s caseback appear to be punched rather than engraved. See the material displacement around to the letters on the picture below? This effect occurs only as a result of punching/stamping.
A closer look at the curves shows they were made with straight lines. This was clearly not engraved.
Applying the inscription in this way must have been a Sisyphean task, meaning it took very long to get it done. This was probably the reason why the other watches were engraved which in turn is just another indication that Brauer’s watch was the very first to feature this designation.
LATE 2000
BRAUER’S PROTOTYPE ENTERS
THE COLLECTORS MARKET
As mentioned earlier, after inheriting all of Dr. Ralph W. Brauer’s belongings, the University of North Carolina Wilmington sold some of his more worldly possessions while keeping thousands of papers and art items intact like the Japanese wood-cut engraving below.
This is how Brauer’s important piece of horological history entered the watch collectors market in late 2000. The watch was acquired by a collector duo that used to work together back in the day. One of them was none other than the famous Paneristi named Hammer aka Alan Bloore. Unfortunately, Hammer never got the chance to see the watch in the flesh as his business partner—who bought the watch from the university—posted Single Red Sea-Dweller on an old Rolex collector forum and quickly received an offer which Hammer could not match at the time in order to become the sole owner of the watch. Hammer, sensing the importance of this watch, had to let it go and regrets this to this day as the following forum post from April 2012 states.
There is another interesting angle to this watch worth mentioning. After Hammer’s business partner sold the watch, delivery and pick-up took place on September 11, 2001 in New York. Basically, this very watch was at the epicenter of an event that sent shock waves around the world.
The following timeline is a summary of the above written. It shows Brauer’s watch in its historical context. Please click the graphic to zoom in for all the great detail.
Brauer’s Single Red Sea-Dweller was published in all detail in the book A Journey Into The Deep by John Goldberger. This volume offers an amazing overview of incredibly rare Rolex dive watches. Many of the pictures published in this article were provided by Mr. Goldberger.
THOUGHTS
Brauer’s watch was one of the first Rolex Single Red Sea-Dwellers recorded in my database. I remember how confused I was about the unique case number. I was aware of the water tight provenance but the case number made little sense to me. After four months of extensive research, I came to realize the importance of this piece and believe the truth about this amazing piece of history has finally come to the surface. The Genesis of the Rolex Sea-Dweller was always there, hiding in plain sight.
The above picture shows Dr. Brauer next to a 20-foot mini-submarine acquired by the Wrightsville Marine Biomedical Laboratory for their research. On his wrist, his unique Single Red Sea-Dweller.
The second part of The Sea-Dweller Chronicles which will cover the time between 1969 and 1971 will be published soon. Thank you for your interest.
Special Thanks To:
Bob Roer
Marc Wright
Eddy Stuart
Peter B. Bennett
Ian Koblick
HISTORY OF THE ROLEX SEA-DWELLER
The development of the Rolex Sea-Dweller goes hand in hand with man’s persistence to push the boundries and reach never thought possible depths. The following infographic shows the evolution of the Sea-Dweller in its historical context.
Final Thoughts by Jake
Jose and I decided to publish his amazing article simultaneously on both Perezcope.com and RolexMagazine.com as we want it to get out to the largest audience possible. Years ago I coined the term 'Horological Forensics Investigator' to describe Jose's AMAZING research and storytelling skills. Jose is like the Dog Whisper of Horology :-0
Jose and I have been great friends and collaborated together for years to bring the world the true history of Rolex and Panerai watches. Something tells me the best is yet to come!!!
